Proportional Directional Control Valves
HUADE 4WRA
BEIJING HUADE 4WRA 10 B 24Z4 /G24 N9 – 95 L/min – 31.5 MPa – Subplate Mounting
Control hydraulic direction and volume flow up to 95 L/min via direct-actuated proportional solenoids. This 4WRA 10 B 24Z4 /G24 N9 features a spring-centered control spool and operates in open-loop systems. Current price available from Parts Trading Corporation.
-
Max Operating Pressure: 31.5 MPa (315 bar)
-
Voltage / Coil configuration: 24 VDC with 1.5 A max current per solenoid
-
Mounting Standard: ISO 4401 Type 4WRA10 subplate mounting
-
Protection rating: IP65 insulation to DIN 40 050
